Name: HC1509/HC1709
Type: HC1509/HC1709

Model HC1509/1709
Voltage 220V 50Hz  / 110V 60Hz
Air flow rate 35L/min@8 bar，60L/min@8bar
Speed 1440 rpm /1700 rpm
Noise ≤52dB(A)
Net Dimension 640*270*550 mm
Weight 18.5 KG
Tank 9L

Product details

Technical specification:

Model

Voltage

Power

Air flow rate

Tank

Net Dimension

Weight

(L*W*H) CM

(KG)

HC1509

220V/50HZ
110V/60HZ

550W

102 L/min@0 bar
70 L/min@2 bar
55 L/min@4 bar
46 L/min@6 bar
35 L/min@8 bar

9 L

64*27*55

18.5

0.75 HP

HC1709

750W

135 L/min@0 bar
115 L/min@2 bar
93 L/min@4 bar
66 L/min@6 bar
60 L/min@8 bar

9 L

64*27*55

18.5

1.0 HP
