Name: HC100D2
Type: HC100D2

Voltage : According to your requirements ;


Air flow rate : 60 LPM  @ -92 Kpa ; (One-Grade vacuum)

                     30  LPM @ -98 Kpa ; (Two-Grade vacuum)


Power: 90 W ;


Noise : ≤42dB(A) ;


Speed: 1700rpm ;



Thermal protector : 135℃



Dimension: 176×95×147 mm



Weight: 2.8 kg

Product details


Drawing:




Product show:
